Conveyor Platform 输送平台
The platform made of new type aluminum, which have advantages of small weight, convenient adjustment and adapt to various production needs.
Double chain hydraulic system controls the rise and fall of the platform, with reliable structure and safe operation.
The rear-end of the platform is equiped with pressing bar to make the paperboard fall horizontally.
Both ends drived for independent servo motor.
Suction structure transmission, to make paperboard stable in high speed transmission.
Front-end Paper Receiving Arm 前端接纸臂
The paper receiving arm is fixed so that the paperboard can be transported smoothly at high speed.
Independent servo motor drives front paperboard receiving segment, speed adjustable.
The front paperboard receiving area is equipped with a combination of pressing bar and medium pressure fan to make the paperboard enter and convey more smoothly; this structure can manually adjust the distance.
Paper Receiving Baffle 接纸挡板
According to paperboard sizes, distance of rear receiving baffle can be adjusted to stack paperboard with different sizes.
Pneumatic slight forward push device and left-right patting device are equiped onto fron receiving baffle to make paperboard can
fall down and stack up smoothly.
Left-right patting device is manual adjustment, easy to operate.
